Outdoor Linear Strobe Light
Overview:
DLW L784C4ST IP is a creative color strobe light and visual effect strip light that adds sparkle to any performance! The fixture is one-meter-long pixel line containing 672 0.5w rgb LEDs distributed in 32 sections around its perimeter while the central flash strip 112 3W cool white LEDs divided into 16 sections. By lining up many fixtures, they create intense, eye-catching bursts of white or colored light into your performances, enhancing the energy of the moment, bringing impressed and stimulating experience when synchronized rhythmic flashes to music. With electronic atomization and smooth dimming, the linear strobe light creates a psychedelic stroboscopic effect.
Built tough with IP66 protection, the DLW L784C4ST IP LED strobe light stand out anywhere—indoors, outdoors, rain or shine. Its robust housing supports end-to-end linking for continuous runs, while versatile mounting options (fixed brackets + swappable folding hooks) make installation a breeze for both permanent and touring setups. Ideal for stages, festivals, architectural accents, and immersive environments.
Key Feature:
Color light: 672 x 0.5w rgb LED across 32 individual control zones, beam 101°/spot 149° zoom
White light: 112 x 3w cw LED in 16 individual control zones, beam 108°/spot 152° zoom
Electronic atomization effect
Advanced strobe effect
IP66 Rating
Send Inquiry
Product Details of Outdoor Linear Strobe Light
Electrical Parameters
Input voltage: AC100-240V 50/60Hz
Input power: 400W
Maximum input current:4A
Light Source Parameters
Color light: RGB LED 0.5W x 672
White light: CW LED 3W x 112
LED lifespan: 20,000 hours
Optical Parameters
Color light beam/spot angle: 101°/149°
White light beam/spot angle: 108°/152°
Effect Configuration
32 individually controllable color light sections
16 individually controllable white light sections
Electronic atomization effect
Powerful strobe effect
High refresh rate
0-100% smooth dimming function
Electronic Control Technology
Control Mode: 7/15/21/39/112/17/33/65/68/117/70CH
Control Protocols: DMX512, RDM; Art-Net, sACN (optional)
Control Interface: XLR-3 + XLR-5; RJ45 (optional)
Power supply unit: Waterproof Locking Power In/Out;
Menu Display: OLED display with 4 touch button
Electronic sensing detection, intelligent fan monitoring and control.
Size and Weight
Fixture Size: 1020 x 97 x 153 (mm)
Fixture Weight: 9.5 kg
Flight Case Size: 1085 x 725 x 573 mm (8 positions)
Flight Case Weight: 38 kg
Conditions of Use
Minimum and maximum ambient temperature: -20°C to 40°C
Protection rating: IP66
Specifications and documentation subject to change without notice.
