Profile Moving Light

DREAM L1400P PLUS
DREAM L1400HP PLUS

Outline
DREAM L1400P PLUS is a quiet theatrical lighting fixture, which is an LED automated profile light, moving lights in theatre.
The fixture utilized 1400W White LED module, produce powerful lighting with exceptional efficiency, it creates sharpy beam as narrow as 5 degree angle. A wide range of features are included in the package, such as a fast motorised iris, prism and dual frost filters, static gobo, rotating gobo wheel, animation wheel, colour wheel, a CMY system linear CTO for abundant colour mixing, offering stunning colours and rich graphic projections.
Additionally, the high precise farming system with continuous rotation allow for endless and limitless aerial effects. The optics' state-of-the-art design offers optimal lighting efficiency, flawless zooming, and excellent precision.

● Light source: 1400W White LED module
● Zoom range: 5°~ 50°
● CMY + CTO
● One color wheel
● One static gobo wheel
● One rotate gobo wheel
● One animation wheel
● Infinite rotate framing system
● Motorized iris, linear adjustment
● One prism, dual frost filters
● Linear adjustment for dimmer

Send Inquiry

Product Details of Profile Moving Light

Electrical

Input voltage: AC100-240V 50/60Hz

Input Power: 1650W, PF≥0.98

Maximum input current: 16.5A

Light Source

Light source: 1400W White LED module (choice of high brightness mode or high CRI mode)

CRI: Ra ≥ 70 (DREAM L1400P PLUS high brightness)

Ra ≥ 95 (DREAM L1400HP PLUS high CRI)

LED module lifespan: 20000 hours

Optics & Photometric Data

Lens: High-definition lens with anti-reflective film

Zoom range: 5°~ 50°

Color System

CMY infinite mixing, output high saturated color (RGB), pure color.

CTO color temperature linear adjustable 3200-6200K

One color wheel, has 7 color filters plus open (included a CRI boost filter), can be bidirectional scrolling, can create effects of rainbow, stepping, sliding fade and random color mode.

Gobo System

One rotate gobo wheel with 6 gobos, the gobos can be indexing and bi-directional rotating, can be self-rotation, create effects of flowing water and shaking, the gobo wheel can be accurately controlled at 16bit.

One static gobo wheel with 9 gobos + 1 open, the gobo wheel can create bidirectional flowing effect.

One animation wheel, can imitate clouds, fire and flowing water for effects.

Framing System

One complete infinite rotatable framing system, 4 x individually controllable full curtain blades with full variable angle through the entire insertion path, can make the framing graphics 360° infinite rotating and accurately positioning, without distortion.

Effect Configuration

One 4-facet prism with rotation in both directions.

Dual frost filters, linear soft and uniform light, high brightness output.

0-100% linear dimmer, choice of 4 dimming curves, choice of 4 dimming speeds.

Electronic strobe with speed adjustment from 1 to 25 flashes per second, multiple strobe options.

High speed motorized iris 5-100% linear adjustment, built-in macro function with multiple effects.

Fixture Movement

PAN = 540° - 16 bit

TILT = 270° - 16 bit

Electronic Control

Channel: 32Ch/ 35Ch/ 60Ch

Control mode: DMX512, RDM; Art-Net, sACN, wireless function (optional)

Control portal: XLR-3 + XLR-5; RJ45 (Optional)

Menu display: 3.5" LCD color touch screen; choice of Chinese and English language, menu available to display 180° reversely

Built-in self-rechargeable battery, menu edit available when without power (optional); Support external charging bank to enter the menu to set address code and other settings

Electronic sensing detection, fan intelligent detection and control

Eco mode (sleep mode when standby)

Non-touch magnetic encoder positionable system for pan-tilt

Size & Weight

Fixture size: (470X470X894) mm

Fixture weight: 48KG

Flight case size: (760X550X890) mm (1 position)

Flight case weight: 34KG

Working Conditions

Minimum and maximum ambient temperature: -20℃~ 40℃

Protection rating: IP 20

Specifications and documentation subject to change without notice.
