LED Wash Fixture
Outline
The DLW L1507C4B IP waterproof LED Wash fixture combines a wide zoom range, fast sweeping beams, and powerful, far-reaching wash effects in a compact and lightweight housing. Its low-maintenance IP66-rated design enables reliable outdoor operation, protecting the fixture from rain, dust, humidity, smoke, and haze—even in the harshest environments.
An advanced optical system, paired with innovative lens coating technology, delivers brighter output, and reduced maintenance. With a versatile 3°–60° zoom range, the fixture produces a smooth, even wash with soft edges and excellent color homogenization.
Powered by 7 × 150W RGBL multi-chip LEDs, with individual pixel control and built-in macro effects, it creates vibrant color chases and seamless transitions, adding dynamic visual impact to any application.
A highly optimized motor system ensures fast and precise pan and tilt movement. In addition to powerful strobe capabilities, the L1507C4B IP Wash Beam fixture offers refined dimming performance and linear color temperature adjustment from 1800K to 10000K, providing a creative flexibility.
Send Inquiry
Product Details of LED Wash Fixture
Electrical
Input voltage: AC100-240V 50/60Hz
Maximum Input Power: 1150W
Maximum input current: 11.5 A
Light Source
Light source: LED 150W *7 RGBL 4 in 1
LED module lifespan: 20000 hours
Optics & Photometric Data
Zoom range: 3°～ 60°
Effect Configuration
Single-Color Single-Point Control, preset multiple macro effects
Color temperature varies linearly from 2500K to 10000K
0-100% electronic dimming control, 4 dimming curve options
Fast strobe 1～25Hz
Fixture Movement
PAN= 540° - 16 bit
TILT= 220° - 16 bit
Electronic Control
Control model： 22 CH / 35 CH / 53 CH;
Control Protocols: DMX512, RDM; Art-Net, sACN,wireless function(optional)
Data Portals: Waterproof XLR-3+ XLR-5; (optional Ethernetport : RJ45 In/Out)
Power Portals : Waterproof Locking Power In/Out
Menu screen： 1.77" LCD color screen, menu display can be 180°reversed
Electronic sensing detection, intelligent fans monitor,control temperature
Supports energy saving mode, standby hibernationfunction
Non-touching magnetic encode position system for pan-tilt
Size& Weight
Fixture size: 438x438x580 mm
Fixture net weight: 27 kg
Flight case size: 923.2x513.2x792 mm (2 positions)
Flight case net weight: 34 kg
Carton size: 670x465x530 mm (1 positions)
Working Conditions
Working environment temperature: -20℃~40℃
Protection rate: IP66
